Product Overview
Ground Sheet for Gazebo is a coated Oxford floor material for use under gazebos, canopies, event shelters, camping awnings, and temporary outdoor rooms. It can be laid over grass, soil, paving, and other surfaces when a separate floor layer is needed.
Key Data Table
|
Property |
Value |
|
Base Fabric |
600D×600D oxford |
|
Weight |
220 g/m² |
|
PEVA Thickness |
0.15mm |
|
Water Resistance |
10000 mm H₂O (ISO 811) |
|
Tensile Strength (Warp / Weft) |
2000N / 1800N (ISO 1421) |
|
Eyelet Pull Strength |
300N |
|
Abrasion (H18, 1000g, 500 cycles) |
No hole |
|
UV Aging (500h QUV) |
>85% strength retained |
|
Mold Resistance (ISO 846) |
Grade 0 |
|
Folded Size (2m×2m) |
30cm × 25cm × 8cm |
|
Weight for 2m×2m piece |
Approx. 800 grams |
Key Advantages
Moisture Barrier for Ground Contact
The 0.15 mm PEVA layer is rated to 10,000 mm H₂O water resistance. On wet grass, damp soil, or rain-soaked ground, it acts as the floor barrier between the surface below and equipment, furniture, or foot traffic inside the shelter.
Anchoring Strength at Tension Points
The 600D Oxford base reaches 2000 N warp and 1800 N weft tensile strength, and each eyelet is specified for 300 N pull strength. These values matter at corners and side fixing points, where stakes and ropes place concentrated loads on the sheet in windy conditions.
Wear Resistance on Rough Surfaces
With an H18 abrasion wheel, a 1000 g load, and 500 cycles, the material is rated as having no hole. That gives the ground sheet a defined abrasion reference for paving, compacted soil, gravel edges, and repeatedly walked entrance areas.
Customization
Size & Shape
The current reference size is 2 m×2 m. Square or rectangular sheets can also be cut to the internal footprint of gazebos, canopies, market shelters, or event structures.
Eyelets & Edge Construction
Eyelet quantity, spacing, and position can be set to the anchoring plan. Bound edges, reinforced corners, and additional fixing points can be added where larger floor areas or wind-exposed installations need them.
Branding & Accessories
Solid colors, logo printing, carry-bag presentation, and project-specific labeling can be prepared for retail, rental, or gazebo accessory orders.
Quality Control
- The finished ground sheet is checked against a 600D×600D Oxford base, 220 g/m² finished weight, and 0.15 mm PEVA thickness. These are the core material controls for the current construction.
- Acceptance values include 10,000 mm H₂O water resistance to ISO 811 and 2000 N warp / 1800 N weft tensile strength to ISO 1421. Eyelet pull strength is 300 N. Abrasion is rated as no hole after H18 / 1000 g / 500 cycles, strength retention is more than 85% after 500 h QUV aging, and mold resistance is Grade 0 to ISO 846.
- Every completed sheet receives 100% inspection before packing. Third-party inspection is also accepted before shipment when the order calls for it.
FAQ
Q: Which shipping term is available?
A: FOB is supported for export orders.
Q: What are the payment terms?
A: Regular orders use 30% deposit and 70% balance; custom-made orders use 50% deposit and 50% balance.
Q: Which side should face the ground?
A: Place the PEVA barrier toward the ground unless the finished-product design specifies another orientation.
Q: Can the sheet be stored immediately after rain?
A: Dry it before folding and storage.
