Product Overview
PVC Coated Tent Fabric is a heavy PVC-coated polyester grid material for large-span tents, temporary halls, carports, military-style shelters, container covers, and other outdoor structures that place high loads on the fabric panels.
Key Data Table
|
Property |
Value |
|
Base Fabric |
1000D×1000D polyester grid |
|
Grid Spacing |
5mm |
|
Base Weight |
360 g/m² |
|
PVC Thickness |
0.55mm double sided |
|
Finished Weight |
680 g/m² |
|
Water Resistance |
15000 mm H₂O (ISO 811) |
|
Tensile Strength (Warp / Weft) |
4000N / 3800N (ISO 1421) |
|
Tear Strength (Warp) |
350N (ASTM D1424) |
|
Low Temperature Flexibility |
No cracks at -30°C (ISO 4675) |
|
UV Aging (2000h Xenon) |
>80% strength retained |
|
Flame Retardant |
DIN 4102 B1, NFPA 701 |
|
High Frequency Weld Peel Strength |
18 N/cm |
|
Mold Resistance (ISO 846) |
Grade 0 |
Key Advantages
Reinforced Structure for High Panel Loads
The 1000D×1000D polyester grid reaches 4000 N warp and 3800 N weft tensile strength, with 350 N warp tear strength. Those values provide the material reference for large roof panels that see wind suction, snow load, repeated tensioning, and handling around seams, corners, and attachment zones.
Heavy Double-Sided Weather Barrier
A 0.55 mm PVC build gives a finished weight of 680 g/m² and 15,000 mm H₂O water resistance. The double-sided coating protects both sides of the textile base during long outdoor exposure in semi-permanent shelters, rental structures, and covers.
Fabrication Stability in Cold Conditions
High-frequency weld peel strength is 18 N/cm, and the material shows no cracking at -30°C. The coating can be welded during fabrication and still remain workable when panels are bent or tensioned during cold-weather installation and dismantling.
Customization
Weight & Construction
Lighter or heavier PVC-coated polyester constructions are available for sidewalls, roofs, storage halls, transport covers, and other structural-fabric uses. Base scrim and coating weight are selected according to panel load.
Color & Surface
Color can be matched to solid RAL/Pantone-style references. Matte or gloss finishes, printable surfaces, and acrylic/PVDF-type topcoat directions can also be specified for branding, cleaning requirements, and outdoor exposure.
Performance & Fabrication
Available directions include flame-retardant, UV, anti-mildew, cold-resistant, and weld-optimized constructions. Roll dimensions, keder zones, reinforced edges, and other downstream fabrication requirements can be incorporated into the order specification.
Quality Control
- The production reference is a 1000D×1000D polyester grid with 5 mm reinforcement spacing, 360 g/m² base weight, a 0.55 mm double-sided PVC build, and 680 g/m² finished weight.
- Acceptance values include 15,000 mm H₂O water resistance to ISO 811, 4000 N warp / 3800 N weft tensile strength to ISO 1421, 350 N warp tear strength to ASTM D1424, and no cracking at -30°C to ISO 4675. The specification also requires more than 80% strength retention after 2,000 h xenon aging, DIN 4102 B1 and NFPA 701 flame-retardant ratings, 18 N/cm high-frequency weld peel strength, and Grade 0 mold resistance to ISO 846.
- Finished rolls are inspected 100% before packing. Third-party inspection can be carried out before shipment when required.
FAQ
Q: Which shipping term is available?
A: FOB is supported for export orders.
Q: What are the payment terms?
A: Regular orders use 30% deposit and 70% balance; custom-made orders use 50% deposit and 50% balance.
Q: How should the surface be cleaned between rental cycles?
A: Use clean water or a neutral detergent and avoid aggressive solvents that can attack the PVC surface.
Q: Is roll storage better than long-term folded storage?
A: Yes. Roll storage is preferred for long inventory periods because it avoids hard crease lines in the heavy coating.
